Kilns system

The offer includes the construction and launch of the kilns in Europe. Extra charge outside Europe.

The offer does not include transport.

For sale - 3 kilns. Excellent technical condition; visual condition as per photos. Kilns has been dismantled and standing in our warehouse (heated facility) since summer of 2021. We can arrange an assembly of the kilns in the buyers location. For any further questions and inquirys, please feel free to contact us.

Design basis:

• Type of wood - Spruce
• Density at 0% HF - 420 kg/m3
• Wood thickness - 60 mm and 120 mm
• Stack bar - 25 mm
• Initial moisture max - 60%
• Final moisture - 17%

Drying equipment:

• Number of fans - 7 pieces with 7.5kW per motor
• Air performance - 280.000 m3/h, reversible
• Air speed - 4.0 m/s at 60 mm wood thickness
• Installed heating capacity - 600 kW = 387,000 kcal/h
• Max drying temperature - 75C
• Heating medium - 95/80 C hot water
• Fresh air exhaust air flaps - 4 pieces
• Spray medium - 20 bar, hot water 80 C
• Spray systems - 2 pieces by dryer

Output (per dryer):

• 6900 m3 at 60mm
• 3800 m3/year at 120 mm

Initial moisture 60 % and useful life of:

• 340 days/year
